FM13UF02E is primarily designed for long destance tag applications such as inventory management,Supply chain management and asset management in different areas of the industry and commerce. This IC belongs to a product family of UHF label ICs based on the EPC Global Class1 Gen2 and ISO/IEC 18000-6C Protocol which has industry leading RF perfomance and reliability of EEPROM.Please consult Fudan Micro Electronics Company for more documents.


1.1 Introduction
FM13UF02E is primarily designed for long distance tag applications such as inventory management, Supply chain management and asset management in different areas of the industry and commerce. This IC belongs to a product family of UHF label ICs based on the EPC Global Class1 Gen2 and ISO/IEC 18000-6C protocol which has industry leading RF performance and reliability of EEPROM. Please consult Fudan Micro Electronics Company for more documents.

1.2 Features
1.2.1 RF Interface
•EPC Global Class1 Gen2 1.2.0 & ISO/IEC 18000-6C
•Operating frequency range: 840~960 MHz
•Contactless transmission of data and supply energy (no battery needed)
•Read sensitivity up to -19 dBm with a dipole antenna
•Industry leading write sensitivity of up to -17 dBm with a dipole antenna
•Industry-leading memory write speed enables encoding rates of over 50 tags/second with 96 bits EPC data
•Support EAS (Electronic Article Surveillance)
•Data transfer: Forward link: 40~160 Kbits/s Return link: 40~640 Kbits/s

1.2.2 EEPROM
•96-EPC Bits, extensible to 496 Bits
•1248 User Bits
•192 Bits Unique TID
•32 Bit Access and 32 bit Kill Passwords
•Data retention of 50 years
•Write endurance 100000 cycles

1.2.3 Security
•Unique identifier for each device, TID is unchangeable.
•Support Block-lock and BlockPermalock
•Support privacy memory which protected by password

1.2.4 Applications
•Retail Inventory management
•Supply chain management
•Loss prevention
•Asset management
•Baggage Handling and Tracking
•Product Authentication
